MATERIALS & APPLICATIONS GUIDE
OUR MATERIALS




GREATER STIFFNESS AND RESISTANCE
Allows for reduced thickness.CHEMICAL BOND WITH ACRYLIC
Possibility of relining and additions using conventional materials and techniques. Ideal for full dentures, overdentures and temporary dentures.MINIMAL SHRINKAGE
High fidelity in all applications.SUPER EASY POLISHING AND BRIGHT SHINE
Saves working time. Optimal and result.CE
ANVISA Nº 80383780003
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Soft pink | Mid intense | Very high | Preferably for full dentures |
![]() Translucent soft pink | Translucid soft | Very high | Preferably for full dentures |
![]() Medium pink | Medium | Medium | Preferably for full dentures |
![]() Transparent | Total |
DIMENSIONS AND WEIGHT
SMALL ∅ 22X55MM / 15,6G
SMALL ∅ 25X50MM / 16,5G
MEDIUM ∅ 22X85MM / 23,9G
MEDIUM ∅ 25X70MM / 24G
LARGE ∅ 22X120MM / 32,3G
LARGE ∅ 25X90MM / 30,8G




RECOMMENDED FOR ALL TYPES OF PARTIAL DENTURE DESIGNS
Recommended for all types of partial denture designs.
OCCLUSAL RESTS
Made using the same polyamide.
HIGH BRIGHTNESS AND TRANSLUCENCY
The material reveals the patient’s gum and tooth color.
CE 2195
ANVISA Nº 80383789001
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Palide pink | Palide | Very high | Preferentemente para prótesis parciales |
![]() Rosa Suave | Suave | Muy alta | Preferentemente para prótesis parciales |
![]() Rosa Medio | Intensa Intermedia | Alta | Preferentemente para prótesis parciales |
![]() Rosa Oscuro | Oscura | Media | Preferentemente para prótesis parciales |
![]() Transparente | Total |
MEDIDAS Y PESOS
PEQUEÑO ∅ 22X55MM / 13,0G
PEQUEÑO ∅ 25X50MM / 14,2G
MEDIANO ∅ 22X85MM / 19,9G
MEDIANO ∅ 25X70MM / 19,6G
GRANDE ∅ 22X120MM / 27,4G
GRANDE ∅ 25X90MM / 25,8G




SIMILAR QUALITY TO CLASSIC sr
FLUENCE SR offers a bit more elasticity and resistance than CLASSIC SR. It has a lower degree of translucency, but still very high. Polishing and gloss become virtually identical.SLIGHTLY MORE FLEXIBLE
It maintains a recommended balance between flexibility and stiffness (low elasticity), allowing to offer aesthetically pleasing and functional partial dentures.MORE FLUID INJECTION
Easy to inject; suitable for a wide range of injection molding machines.CE
ANVISA Nº 80383789002
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Medium pink | Mid intense | High | Preferably for partial dentures |
![]() Transparent | Total |
DIMENSIONS AND WEIGHT
SMALL ∅ 22X55MM / 13,7G
SMALL ∅ 25X50MM / 14G
MEDIUM ∅ 22X85MM / 20,5G
MEDIUM ∅ 25X70MM / 20,8G
LARGE ∅ 22X120MM / 27,3G
LARGE ∅ 25X90MM / 26,5G




MEDIUM FLEXIBILITY
For clinical cases requiring greater elasticity without losing stability. For example, cases with diverging teeth pillars.VERY HIGH FRACTURE RESISTANCE
Makes it possible to reduce thickness.EXTREMELY FLUID INJECTION
Suitable for injection into all kinds of equipment.SUPERIOR ELASTIC MEMORY
Compared with the other materials of similar flexibility available in the market, the yield strength (elastic memory) of SUPRA SF is superior, avoiding distortion and loss of functionality over time.CE
ANVISA Nº 80383789003
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Medium pink | Mid intense | Medium | Preferably for partial dentures |
DIMENSIONS AND WEIGHT
SMALL ∅ 22X55MM / 14G
SMALL ∅ 25X50MM / 14,8G
MEDIUM ∅ 22X85MM / 21,3G
MEDIUM ∅ 25X70MM / 22,3G
LARGE ∅ 22X120MM / 29,6G
LARGE ∅ 25X90MM / 28G




MORE RESISTANT AND LIGHTWEIGHT FULL DENTURES THAN CONVENTIONAL ACRYLIC
High impact resistance. Accepts reduced thickness.VERY LOW SHRINKAGE
Volume stability that makes it suitable for complete, occlusal splints and overdentures.HYPOALLERGENIC **
CE 2195
ANVISA Nº 80383780002
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Medium pink | Medium | High | Preferably for full dentures |
![]() Transparent | Total |
DIMENSIONS AND WEIGHT
MEDIUM ∅ 22X85MM / 24G
MEDIUM ∅ 25X70MM / 24,5G
LARGE ∅ 22X120MM / 32,8G
LARGE ∅ 25X90MM / 32,3G




SUITABLE FOR PARTIAL DENTURES FRAMEWORKS AND AESTHETIC RETAINERS
Tooth-colored acetal resin.STIFFNESS, AND HIGH SURFACE HARDNESS
Position it as a valid alternative for chromium-cobalt type frames.LOW LIQUID ABSORPTION
It is not impregnated, does not change color.CE
ANVISA Nº 80383780004

DIMENSIONS AND WEIGHT
SMALL ∅ 22mm / 13G (1 TABLET)
SMALL ∅ 25mm / 17,4G (1 TABLET)
MEDIUM ∅ 22mm / 26G (2 TABLETS)
MEDIUM ∅ 25mm / 34,8G (2 TABLETS)




DEFLEX PEEK (POLYETHER ETHER KETONE) HIGHT PERFOMANCE POLYMER
DEFLEX PEEK is specially suitable for infra-structure of bridges and crowns, especially due to its exceptional strength and biocompatible nature. But is also a very interesting option for the manufacture of removable partial frameworks, and for overdenture structures to be coated with another material. It can be injected into a casting ring or a flask.
Its hardness and strength position it as an alternative that competes with the chromium-cobalt framework, with the differential of being a material free of metal.GREAT HARDNESS AND HIGH WEAR RESISTANCE
BIOCOMPATIBLE AND HYPO-ALLERGENIC**
LOW THERMAL CONDUCTIVITY
100% METAL FREE
COLORS | TONALITY | TRANSLUCENCY | INDICATIONS |
![]() Beige | Opaque | Partial framework. Overdenture structures to be coated with another material | |
![]() Pink | Opaque | Partial framework. Overdenture structures to be coated with another material |
DIMENSIONS AND WEIGHT
SMALL 20g
MEDIUM 40g
Guidance table
for the choice of materials
according to its main applications in removable dentures:
APPLICATIONS
MATERIALS
DESCRIPTIONS
APPLICATION

MATERIAL



DESCRIPTION
In order, from the most rigid to the most flexible. Select according to flexibility need of the denture. More rigid dentures are easier to polish and shine.
APPLICATION

MATERIAL


DESCRIPTION
Both with chemical bond with the conventional Acrylic resin, and very low shrinkage.
APPLICATION

MATERIAL


DESCRIPTION
Both with chemical bond with the conventional Acrylic resin, and very low shrinkage.
APPLICATION

MATERIAL


DESCRIPTION
Both with chemical bond with the conventional Acrylic resin, and very low shrinkage.
APPLICATION

MATERIAL

DESCRIPTION
Injectable acetal with tooth-colored retainers. CLASSIC SR and FLUENCE SR can also be used to make translucent pink aesthetic retainers.
APPLICATION

MATERIAL


DESCRIPTION
ACETAL AC is easy to inject and polish. DEFLEX PEEK has greater strength and rigidity.
APPLICATION

MATERIAL



DESCRIPTION
M10 XR and ACRILATO FD can be indicated as coating of metallic structures. DEFLEX PEEK allows to make structures of overdentures to be coated in composite resin, or in self-curing acrylics, or thermo-curable acrylics with a low polymerization temperature.
COLORS
A subtle range of roses satisfies the diverse colors of patient’s gums.

Semi-rigid polyamide

Semi-rigid polyamide

Semi-flexible polyamide

Extra-rigid polymer

Injectable acrylic

Palide pink

Sof pink

Translucent soft pink

Medium pink

Dark pink

Transparent

Injectable acetal






PROPERTIES
ELASTICITY
HIPO-ALLERGENIC
CHEMICAL BOND WITH ACRYLIC

ELASTICITY:
Reference value = 0
HIPO-ALLERGENIC:
YES
CHEMICAL BOND WITH ACRYLIC:
YES*

ELASTICITY:
44%

HIPO-ALLERGENIC:
YES
CHEMICAL BOND WITH ACRYLIC:
SI*

ELASTICITY:
-6%

HIPO-ALLERGENIC:
YES
CHEMICAL BOND WITH ACRYLIC:
NO

ELASTICITY:
-63%

HIPO-ALLERGENIC:
YES
UNIÓN QUÍMICA C/ACRÍLICO:
NO

ELASTICITY:
-6%

HIPO-ALLERGENIC:
YES**
CHEMICAL BOND WITH ACRYLIC:
YES*

ELASTICITY:
+81%

HIPO-ALLERGENIC:
YES
CHEMICAL BOND WITH ACRYLIC:
NO

ELASTICITY:
+125%

HIPO-ALLERGENIC:
YES
CHEMICAL BOND WITH ACRYLIC:
NO

GREATER FLEXIBILITY

GREATER RIRIDITY
Injection parameters
TEMPERATURE
INJECTION TIME
HOLDING TIME
AIR PRESSURE

TEMPERATURE:
280ºc +/- 10ºC
INJECTION TIME:
15 min
HOLDING TIME:
1 min
AIR PRESSURE:
6 Kg/cm2 +/- 1
= 86 PSI +/- 14

TEMPERATURE:
305ºc +/- 10ºC
INJECTION TIME:
15 min
HOLDING TIME:
1 min
AIR PRESSURE:
6 Kg/cm2 +/- 1
= 86 PSI +/- 14

TEMPERATURE:
275ºc +/- 10ºC
INJECTION TIME:
15 min
HOLDING TIME:
1 min
AIR PRESSURE:
4,5 Kg/cm2 +/- 0,5
= 64 PSI +/- 7

TEMPERATURA:
260ºc +/- 10ºC
INJECTION TIME:
12 min
HOLDING TIME:
1 min
AIR PRESSURE:
4,5 Kg/cm2 +/- 0,5
= 50 PSI +/- 14

TEMPERATURE:
265ºc +/- 10ºC
INJECTION TIME:
15 min
TIEMPO DE SOSTENIMIENTO:
1 min
AIR PRESSURE:
6 Kg/cm2 +/- 1
= 86 PSI +/- 14

TEMPERATURA:
220ºc +/- 5ºC
INJECTION TIME:
15 min
HOLDING TIME:
1 min
AIR PRESSURE:
4,5 Kg/cm2 +/- 0,5
= 86 PSI +/- 14

TEMPERATURE:
*
INJECTION TIME:
*
HOLDING TIME:
*
AIR PRESSURE:
*
* Injection parameters for OSSIS TI depend on the applied model and injection technique. Refer complete technical indications for different techniques and applications.
COMMERCIAL PRESENTATION

Thermo-injectable materials presented in the form of small granuls or tablets.
Pre-dried, colored and packed in aluminum tubes.
Small cartridges: suitable for very small RPD’s and aesthetic retainers
Medium cartridges: for conventional RPD’s, frameworks and occlusal splints
Large cartridges: indicated for full dentures, large RPD’s and overdentures
Available in two different diameters: 22mm y 25mm
Expiration date: 24 months



Diameter 22 mm
- Small (x 55 mm)
- Medium (x 85 mm)
- Large (x 120 mm)
Diameter 25 mm
- Small (x 50 mm)
- Medium (x 70 mm)
- Large (x 90 mm)
